【Brief introduction of goods】：
With step-by-steps the board to pass on a system, uses with the chain fingernail synchronization chain link type design, durably, does not have the noise, the transmission is steady. The control system, the industry kiln computer, signal hearing processing, the system stable is reliable. The far infrared pre- vulcanization system, prevents the temperature drop. Uses the new turbo-charged welding flux spreading system, survives the winter the atomization to be even, effectively reduces the welding flux amount used. The transportation system uses the import motor transmission, and is loaded with the overload protector. The foundation plate width uses the computer control automatic control, facilitates reliably.
|
|
【Remarks】：
Technical parameter:
Pre- thermal region (infrared + hot blast): 4Kw * 2
Preheating temperature: Room temperature ~180
Preheating controls the warm way: PID pattern
Tin stove radiator pipe power: 2Kw * 8
The welding controls the warm way: PID pattern
Wave ridge motor: Imports the thermostable motor
Soldering tin capacity: 380kg
PCB width: Max.250mm
PCB transmission speed: 0.5~1.8m/min
Transmission motor power: 90W
Total output: 36Kw
Work power: 18Kw
Power source: 3,5W,380V,50Hz
Is mad the source: 5Mpa
Atomization barometric pressure: 0.25Mpa~0.4Mpa
Spray gun drive type: Outside the need sets at the spraying machine
Cooling system: 3P
External dimensions (L*W*H) mm: 4,120 *1280 *1630
Weight: Approximately 1050kg
|
