【Introduction】：
1.Temperature control Zone: 6, up 3/below 3.
2.Temperature control accuracy: ± 3℃
3.Heating: The heating time from room-temperature to set point takes less than 40minutes.
4.Conveyor width: 300mm..
5.Max. PCB width: 300mm.
6.Conveying speed: 0-1.5 m/min, Panasonic frequency conversion for speed adjustment.
7.Working conditions: Room temperature 10℃ ~ 40℃, relative humidity ＜85%.
8.Continuous working hours: 10 hours
9.Power supply: AC 220V±10%, maximum power consumption 7.5kw, working power consumption 5kw,
provided with UPS, output load capacity 500VA/300W.
10.Dimension： 1700 × 620 × 1400mm (Length×width×height)
11.Weight：circa
180Kg
。
【Remark】： |
